Chapter 4: Receiver
CLK_COR_SEQ_1_ENABLE 4-bit Binary Mask enable bit for the first clock correction sequence.
CLK_FOR_SEQ_1_ENABLE[0] is the mask bit for CLK_COR_SEQ_1_1.
CLK_FOR_SEQ_1_ENABLE[1] is the mask bit for CLK_COR_SEQ_1_2.
CLK_FOR_SEQ_1_ENABLE[2] is the mask bit for CLK_COR_SEQ_1_3.
CLK_FOR_SEQ_1_ENABLE[3] is the mask bit for CLK_COR_SEQ_1_4.
When CLK_FOR_SEQ_1_ENABLE[*] is 0, the corresponding
CLK_COR_SEQ_1_* is either considered as a don't care or is matched
automatically without a comparison.
When CLK_FOR_SEQ_1_ENABLE[*] is 1, the corresponding
CLK_COR_SEQ_1_* is compared for a match.
CLK_COR_SEQ_1_1 10-bit Binary First clock correction sequence 1 to be compared when
CLK_FOR_SEQ_1_ENABLE[0] = 1.
CLK_COR_SEQ_1_2 10-bit Binary First clock correction sequence 2 to be compared when
CLK_FOR_SEQ_1_ENABLE[1] = 1.
CLK_COR_SEQ_1_3 10-bit Binary First clock correction sequence 3 to be compared when
CLK_FOR_SEQ_1_ENABLE[2] = 1.
CLK_COR_SEQ_1_4 10-bit Binary First clock correction sequence 4 to be compared when
CLK_FOR_SEQ_1_ENABLE[3] = 1.
CLK_COR_SEQ_2_USE String Set to TRUE if the second clock correction sequence (CLK_COR_SEQ_2_*) is
used in addition to the CLK_COR_SEQ_1_* that is always used.
CLK_COR_SEQ_2_ENABLE 4-bit Binary Mask enable bit for the second clock correction sequence.
CLK_FOR_SEQ_2_ENABLE[0] is the mask bit for CLK_COR_SEQ_2_1.
CLK_FOR_SEQ_2_ENABLE[1] is the mask bit for CLK_COR_SEQ_2_2.
CLK_FOR_SEQ_2_ENABLE[2] is the mask bit for CLK_COR_SEQ_2_3.
CLK_FOR_SEQ_2_ENABLE[3] is the mask bit for CLK_COR_SEQ_2_4.
When CLK_FOR_SEQ_2_ENABLE[*] is 0, the corresponding
CLK_COR_SEQ_2_* is either considered as a don't care or is matched
automatically without a comparison.
When CLK_FOR_SEQ_2_ENABLE[*] is 1, the corresponding
CLK_COR_SEQ_2_* is compared for a match.
CLK_COR_SEQ_2_1 10-bit Binary Second clock correction sequence 1 to be compared when
CLK_FOR_SEQ_2_ENABLE[0] = 1
CLK_COR_SEQ_2_2 10-bit Binary Second clock correction sequence 2 to be compared when
CLK_FOR_SEQ_2_ENABLE[1] = 1
CLK_COR_SEQ_2_3 10-bit Binary Second clock correction sequence 3 to be compared when
CLK_FOR_SEQ_2_ENABLE[2] = 1
CLK_COR_SEQ_2_4 10-bit Binary Second clock correction sequence 4 to be compared when
CLK_FOR_SEQ_2_ENABLE[3] = 1
RX_DATA_WIDTH Integer Sets the bit width of the RXDATA port. When 8B/10B encoding is enabled,
RX_DATA_WIDTH must be set to 20 or 40. Valid settings are 16, 20, 32, and
40.
See Interface Width Configuration, page 214 for more details.
