Xilinx 7 Series User Manual

7 Series FPGAs GTP Transceivers User Guide www.xilinx.com 203
UG482 (v1.9) December 19, 2016
RX Channel Bonding
daisy chain. Daisy chaining is performed using the RXCHBONDLEVEL[2:0] ports to allow
additional pipeline stages between the master and the slave. The RXCHBONDO port of each slave
is used as a pipeline stage in the RXCHBONDO path from the master. Figure 4-48 and Figure 4-49
show two daisy-chain examples.
To set up a daisy chain, the GTP transceivers are first connected using RXCHBONDO and
RXCHBONDI to create a path from the RXCHBONDI port of each slave to the RXCHBONDO
X-Ref Target - Figure 4-48
Figure 4-48: Channel Bonding Daisy Chain Example 1
X-Ref Target - Figure 4-49
Figure 4-49: Channel Bonding Daisy Chain Example 2
RXCHBONDI
RXCHBONDO
RXCHBONDI
RXCHBONDO
RXCHBONDI
RXCHBONDO
RXCHBONDI
RXCHBONDO
RXCHANBONDMASTER = 0
RXCHANBONDSLAVE = 1
RXCHANBONDLEVEL[2:0] = 0
RXCHANBONDMASTER = 0
RXCHANBONDSLAVE = 1
RXCHANBONDLEVEL[2:0] = 1
RXCHANBONDMASTER = 0
RXCHANBONDSLAVE = 1
RXCHANBONDLEVEL[2:0] = 2
RXCHANBONDMASTER = 1
RXCHANBONDSLAVE = 0
RXCHANBONDLEVEL[2:0] = 3
UG482_c4_30_111011
RXCHBONDI
RXCHBONDO
RXCHANBONDMASTER = 1
RXCHANBONDSLAVE = 0
RXCHANBONDLEVEL[2:0] = 2
RXCHBONDI
RXCHBONDO
RXCHBONDI
RXCHBONDO
RXCHBONDI
RXCHBONDO
RXCHANBONDMASTER = 0
RXCHANBONDSLAVE = 1
RXCHANBONDLEVEL[2:0] = 1
RXCHANBONDMASTER = 0
RXCHANBONDSLAVE = 1
RXCHANBONDLEVEL[2:0] = 0
UG482_c4_31_111011
Send Feedback
