Xilinx 7 Series User Manual

220 www.xilinx.com 7 Series FPGAs GTP Transceivers User Guide
UG482 (v1.9) December 19, 2016
Chapter 5: Board Design Guidelines
G11. For each of the GTP Quads in the power supply group, the power supply pins for each GTP
quad are connected to the same planes inside the package. For each power supply group, there is an
MGTAVCC power plane in the package and there is an MGTAVTT power supply plane in the
package. (See Table 5-2 for a description of the connected Artix-7 FPGA GTP Quads.)
Notice in Table 5-2 that there are two types of groupings of the GTP Quads in a column.
• Devices with two power supply groups for GTP Quads in the package
• G10 power supply group for a set of GTP Quads
• G11 power supply group for a a different set of GTP Quads
• Devices with a single power supply group for a GTP Quad
Table 5-2: Artix-7 Devices, Packages, GTP Transceivers, and Power Planes
Artix-7 FPGA GTP Transceivers
MGT113 MGT213 MGT116 MGT216
XC7A12T-CPG236
Single
(1)
XC7A12T-CSG325 Single
XC7A15T-CPG326
Single
(1)
XC7A15T-CSG325 Single
XC7A15T-FGG484
Single
XC7A25T-CPG236
Single
XC7A25T-CSG325
Single
XC7A35T-CPG236
Single
XC7A35T-CSG325
Single
XC7A35T-FGG484
Single
XC7A50T-CPG236
Single
XC7A50T-CSG325
Single
XC7A50T-FGG484
Single
XC7A75T-FGG484
Single
XC7A75T-FGG676
G10
(2)
G11
(3)
XC7A100T-FGG484 Single
XC7A100T-FGG676
G10 G11
XC7A200T-SBG484
Single
XC7A200T-FBG484
Single
XC7A200T-FBG676
G10 G11
Send Feedback
