xiC - Technical Manual Version 1.16
6.1.3.2. What is the real transfer speed?
xiC camera can deliver up to 450Mbyte/sec. This requires that certain conditions are met, see 4.1 System Requirements.
Maximum transfer speeds of different interfaces:
table 6-2, interface depending transfer rates
6.1.3.3. Why can I not achieve maximum transfer speed?
In order to reliably achieve maximum transfer speed it is necessary to verify that you are using recommended hardware (please
see 4.1 System Requirements), and that all software requirements are met.
xiCOP (please see 5.8 XIMEA Control Panel) - XIMEA Control Panel free software tool, facilitates the task of verification of XIMEA
USB3 Vision camera installations.
6.1.3.4. What voltage should be applied to Digital Input of xiC to turn it on/off?
xiC camera features two type of inputs (-UB, -TC only). First is optoisolated input only. Second is INOUT set to input function.
Following table shows different levels of Voltage on Digital Input (VDI) on xiC and their logical interpretation.
table 6-3, voltage levels for optoisolated digital input
table 6-4, voltage levels for non-isolated digital input
Maximal input voltage 24Vdc
6.1.3.5. What is the implementation of Digital Output (VDO) of xiC?
xiC cameras features two kind of digital output:
1. Opticaly isolated digital output - opto-isolated NPN open collector type, max. load current 25mA, max. open voltage 24Vdc.
For more details see also: 3.10.4 Optically isolated Digital Output
2. Non isolated high impedance input/output
For more details see also: 3.10.5 Non-isolated Digital Lines (-UB and -TC only)
