XIMEA xiC - 9 List of Tables

xiC - Technical Manual Version 1.16
115
9. list of tables
table 2-1, advantages 11
table 2-2, common features 12
table 2-3, models overview 14
table 2-4, accessories 14
table 3-1, environment 15
table 3-2, firmware / API features 15
table 3-3, custom screws, technical details 16
table 3-4, monochrome camera - filter glass parameter 17
table 3-5, color camera - filter glass parameter 18
table 3-6, MC023xG-SY, sensor and camera parameters 19
table 3-7, MC023xG-SY, supported standard readout modes 20
table 3-8, sensor features available 23
table 3-9, MC031xG-SY, sensor and camera parameters 24
table 3-10, MC031xG-SY, supported standard readout modes 25
table 3-11, sensor features available 28
table 3-12, MC050xG-SY, sensor and camera parameters 29
table 3-13, MC050xG-SY, supported standard readout modes 30
table 3-14, sensor features available 33
table 3-15, MC089xG-SY, sensor and camera parameters 34
table 3-16, MC089xG-SY, supported standard readout modes 35
table 3-17, sensor features available 38
table 3-18, MC124xG-SY, sensor and camera parameters 39
table 3-19, MC124xG-SY, supported standard readout modes 40
table 3-20, sensor features available 43
table 3-21, LED output description 44
table 3-22, LED status during boot 44
table 3-23, LED output description 44
table 3-24, USB 3.1 mating connector description 45
Table 3-25 USB type C connector pin assignment 45
table 3-26, USB 3.1micro B mating connector description 46
table 3-27, USB 3.0 connector, pin assignment 46
Table 3-28 Connector part numbers 47
Table 3-29 Pin list for flex cable 47
table 3-30, GPIO mating connector description 51
table 3-31, I/O connector Pin Assignment 51
table 3-32, Optically isolated digital input, general info 52
table 3-33, digital info, signal levels 52
table 3-34, digital input, timing 54
table 3-35, Optically isolated digital output, general info 54
table 3-36, digital output, LED driving 58
table 3-37, digital output, wiring examples 60
table 3-38, digital output, typical timing 60
