XIMEA xiC - Mc050 Xg-SY; Sensor and Camera Parameters

xiC - Technical Manual Version 1.16
33
3.5.3. MC050xG-SY
3.5.3.1. Sensor and camera parameters
xiC model
MC050CG-SY
MC050MG-SY
Sensor parameter
Model name
IMX250LQR-C
IMX250LLR-C
Color filter
RGB Bayer mosaic
None
Type
Global shutter, overlap mode
Pixel Resolution (H × V) [pixel]
2464 x 2056
Active area size (H × V) [mm]
8.5 x 7.09
Sensor diagonal [mm]
11.1
Optical format [inch]
2/3
Pixel Size (H × V) [µm]
3.45 x 3.45
ADC resolution [bit]
8, 10, 12
FWC [ke-]
9.8
Dynamic range [dB]
70.8
SNR Max [dB]
40.3
Conversion gain [e-/LSB
12
]
2.66
Dark noise [e-]
2.32
Dark current [e-/s]
3.9
DSNU [e-]
0.75
PRNU %
0.61
Linearity [%]
0.5
Camera parameters
Digitization [bit]
8
3
, 10, 12
Supported bit resolutions [bit/pixel]
8, 10, 12
Exposure time (EXP)
1µs
2
to 30sec, in steps of 6.32µs
1
Variable Gain Range (VGA) [dB]
0-24
Refresh rate (MRR) [fps]
76
Power consumption
typical [W]
2.85
Maximum [W]
3.0
Dimensions/Mass
height [mm]
26.4
width [mm]
26.4
depth (-TC/-UB/-FL/-FV) [mm]
42.2/41.9/28.8/29.3(with C/CS Mount module B)
37.3/36.9/23.8/24.3 (without C/CS Mount module B)
mass (-TC/-UB/-FL/-FV) [g]
38.3/37.5/28.3/28.3 (with C/CS Mount module B)
34.1/33.3/24.1/24.1 (without C/CS Mount module B)
table 3-12, MC050xG-SY, sensor and camera parameters
Notes:
1) Defined for maximal bandwidth. Minimal Exposure and exposure step (Line Period) could be calculated in:
Camera performance calculator:
https://www.ximea.com/support/attachments/download/7828/Camera_Performance_Calculator.xlsm
2) From 1 µs to 14 µs the step is 1µs and the sensor is operating in special mode. This exposure times are not
achievable for exposure controlled by trigger pulse length.
3) Saturation level in 8bit digitization is only ¼ of 10bit and 12bit mode (see 4.2.5 Digitization bit depth)
