3.10.4.4.6. Output Wiring Example: Driving the trigger input of a strobe controller
The digital output can be used to drive a strobe controller according to the table below.
Driving the trigger input of a strobe controller
Trigger
polarity
Opto-isolated
controller input
Output
delay
Wiring
Description
Positive
edge
Yes
0.5µs
figure 3-49
Negative
edge
Yes
0.5µs
figure 3-51
Positive
edge
No
155µs
figure 3-52
Not recommended in cases when short delay time is required.
Output delay is much longer than in other wiring examples. Use
external pull up in case that no pull up at controller input is
used.
Negative
edge
No
0.5µs
figure 3-52
Note that external pull up is not used in this case. Assume that
internal pull up at the controller input is used.
table 3-37, digital output, wiring examples
3.10.4.5. Digital Output – Timing
Typical input delay between FPGA Output to Digital Output
Edge Type
Typ. delay [μs]
Off -> On
0.5
On -> Off
155
table 3-38, digital output, typical timing
Note: Measured at conditions: V
OUTPUT
=18V, T
AMBIENT
=27°C
Output delay depending on output current:
Output current
OFF->ON
ON->OFF
2mA
0.55μs
184μs
5mA
0.55μs
182μs
10mA
0.55μs
133μs
25mA
0.55μs
113μs
table 3-39, digital output, current depending timing
Note: Measured at conditions: V
OUTPUT
=11V, T
AMBIENT
=25°C
