XIMEA xiC - Model Specific Characteristics

xiC - Technical Manual Version 1.16
23
3.5. Model Specific Characteristics
3.5.1. MC023xG-SY
3.5.1.1. Sensor and camera parameters
xiC model
MC023CG-SY
MC023MG-SY
Sensor parameter
Model name
IMX174LQJ-C
IMX174LLJ-C
Color filter
RGB Bayer mosaic
None
Type
Global shutter, overlap mode
Pixel Resolution (H × V) [pixel]
1936 x 1216
Active area size (H × V) [mm]
11.314 x 7.12
Sensor diagonal [mm]
13.39
Optical format [inch]
1/1.2
Pixel Size (H × V) [µm]
5.86 x 5.86
ADC resolution [bit]
10, 12
FWC [ke-]
30.5
Dynamic range [dB]
71.7
SNR Max [dB]
45
Conversion gain [e-/LSB
12
]
8.1
Dark noise [e-]
7.36
Dark current [e-/s]
3
DSNU [e-]
1.1
PRNU %
0.4
Linearity [%]
0.5
Camera parameters
Digitization [bit]
10, 12
Supported bit resolutions [bit/pixel]
8, 10, 12
Exposure time (EXP)
19µs to 30sec, in steps of 4.96µs
1
Variable Gain Range (VGA) [dB]
0-24
Refresh rate (MRR) [fps]
165
Power consumption
typical [W]
2.2
Maximum [W]
2.5
Dimensions/Mass
height [mm]
26.4
width [mm]
26.4
depth (-TC/-UB/-FL/-FV) [mm]
42.3/42.0/28.9/29.4(with C/CS Mount module B)
37.3/37.0/23.9/24.4 (without C/CS Mount module B)
mass (-TC/-UB/-FL/-FV) [g]
38.3/37.5/28.3/28.3 (with C/CS Mount module B)
34.1/33.3/24.1/24.1 (without C/CS Mount module B)
table 3-6, MC023xG-SY, sensor and camera parameters
Notes:
1) Defined for maximal bandwidth. Minimal Exposure and exposure step (Line Period) could be calculated in:
Camera performance calculator:
https://www.ximea.com/support/attachments/download/7828/Camera_Performance_Calculator.xlsm
