Yaesu FTM-100DR/DE User Manual

132
Customizing Menu Settings and User Preferences
Setup menu operations: 4 SIGNALING
Setting the squelch type separately for transmission and reception
(9 SQL EXPANSION)
You can set the squelch type separately for transmission and reception.
1 Press and hold for over one second.
The Setup menu appears.
2 Rotate the DIAL to select [4 SIGNALING], then press
.
3 Rotate the DIAL to select [9 SQL EXPANSION], then
press
.
4 Rotate the DIAL to select the desired setting.
1 ON: Uses different squelch types for transmission
and reception. For details, see “Other squelch
functions” on page 90.
2 OFF: Uses the same squelch for transmission and
reception.
Tip The default setting: 2 OFF
5 Press and hold for over one second.
Sets the squelch type for transmission and reception and returns the display to the
previously viewed screen.
Setting the weather alert operation (USA Version Only)
(10 WX ALERT)
The reception of the weather alert can be disabled.
1 Press and hold for over one second.
The Setup menu appears.
2 Rotate the DIAL to select [4 SIGNALING], then press .
3 Rotate the DIAL to select [10 WX ALERT], then press .
4 Rotate the DIAL to select the desired setting.
1 ON: The weather alert will be received.
2 OFF: The weather alert will not be received.
Tip The default setting: 2 OFF
5 Press and hold for over one second.
Sets the weather alert operation and returns the display to the previously viewed
screen.

Yaesu FTM-100DR/DE Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modulation Types	FM, C4FM
Display Type	Color TFT
Memory Channels	1000
GPS	Yes
APRS	Yes
Operating Modes	Simplex, Repeater
Supply Voltage	13.8V DC
Bluetooth	Yes
RF Power Output	50W
