Yaesu FTM-100DR/DE User Manual

42
Basic Operations
Communicating
Adjusting the transmit power
When communicating with a nearby station, the transmit power level may be lowered to
reduce the battery power consumption.
1 Press .
Each time
is pressed, the transmit power level
changes in the following order:
 “HIGH”→“LOW”→“MID”
Model HIGH MID LOW
FTM-100DR/DE 50 W 20 W 5 W
Adjusting the microphone sensitivity
The sensitivity (gain) of the microphone can be adjusted.
1 Press and hold for over one second.
The Setup menu appears.
2 Rotate the DIAL to select [2 TX/RX], then press
.
The menu list appears.
3 Rotate the DIAL to select [2 MIC GAIN], then press
.
The microphone gain setting value appears.
4 Rotate the DIAL to select the desired microphone
gain setting.
 “1MIN”→“2LOW”→“3NORMAL”→“4HIGH”
Tip The default setting: 3 NORMAL
5 Press and hold for over one second.
The microphone sensitivity is set and the display returns to the previous operating
screen.
Tip You can also return to the previous operating screen by pressing 3 times.

Yaesu FTM-100DR/DE Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modulation Types	FM, C4FM
Display Type	Color TFT
Memory Channels	1000
GPS	Yes
APRS	Yes
Operating Modes	Simplex, Repeater
Supply Voltage	13.8V DC
Bluetooth	Yes
RF Power Output	50W
