Yaesu FTM-100DR/DE User Manual

40
Basic Operations
Receiving
Switching the modulation mode
In analog mode, the modulation mode can be selected from “AUTO”, “MANUAL (FM)”
and “MANUAL (AM)”.
When shipped from the factory, the mode is set to “AUTO” where the most optimal
modulation mode is automatically selected according to the frequency.
1 Select the desired operating band.
2 Press and hold for over one second.
The Setup menu appears.
3 Rotate the DIAL to select [2 TX/RX], then press
.
The menu list appears.
4 Rotate the DIAL to select [1 ANALOG MODE
SELECT], then press
.
The modulation mode setting value appears.
5 Rotate the DIAL to select the desired modulation
mode.
“1 AUTO”: Automatically switches the modulation
mode to match the frequency band.
“2 MANUAL(FM)”: Switches to FM mode.
“3 MANUAL(AM)”: Switches to AM mode.
Tip The default setting: AUTO
6 Press and hold for over one second.
Sets the selected modulation mode and returns the display to the previously viewed
screen.
Tip You can also return to the previous screen by pressing 3 times.

Yaesu FTM-100DR/DE Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modulation Types	FM, C4FM
Display Type	Color TFT
Memory Channels	1000
GPS	Yes
APRS	Yes
Operating Modes	Simplex, Repeater
Supply Voltage	13.8V DC
Bluetooth	Yes
RF Power Output	50W
