Yaesu FTM-100DR/DE User Manual

92
Convenient Functions
Using the DTMF function
8 Press and hold for over one second.
Sets the DTMF code and returns the display to the previously viewed screen.
Tip You can also return to the previous screen by pressing 3 times.
Transmitting the registered DTMF code
1 Press and hold for over one second.
The Setup menu appears.
2 Rotate the DIAL to select [4 SIGNALING], then press
.
The menu list appears.
3 Rotate the DIAL to select [3 AUTO DIALER], then
press
.
The AUTO DIALER screen appears.
4 Rotate the DIAL to select “1 ON”
.
Rotating the DIAL changes the function between “1
ON” and “2 OFF”.
5 Press and hold for over one second.
Returns the display to the previously viewed screen and displays
on the top right
side of the screen.
Tip You can also return to the previous screen by pressing 3 times.
6 While pressing and holding [PTT] on the microphone, use the number keys on the
microphone to input the channel number to which the DTMF code is registered.
The DTMF code sequence is automatically transmitted.
7 Release [PTT].
While transmitting the DTMF code, transmission status is sustained even when
[PTT] is pressed.
Transmitting the DTMF code manually
1 Press and hold for over one second.
The Setup menu appears.
2 Rotate the DIAL to select [4 SIGNALING], then press
.
The menu list appears.
3 Rotate the DIAL to select [3 AUTO DIALER], then
press
.
The AUTO DIALER screen appears.

Yaesu FTM-100DR/DE Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modulation Types	FM, C4FM
Display Type	Color TFT
Memory Channels	1000
GPS	Yes
APRS	Yes
Operating Modes	Simplex, Repeater
Supply Voltage	13.8V DC
Bluetooth	Yes
RF Power Output	50W
