Yaesu FTM-100DR/DE User Manual

45
Basic Operations
Other settings
Changing the beep volume
The volume of the key operation “beep sound” can be adjusted.
1 Press and hold for over one second.
The Setup menu appears.
2 Rotate the DIAL to select [8 CONFIG], then press
.
The menu list appears.
3 Rotate the DIAL to select [8 BEEP], then press
.
The volume setting value appears.
4 Rotate the DIAL to select the desired volume level.
 “1OFF”→“2LOW”→“3HIGH”
Tip The default setting: 2 LOW
5 Press and hold for over one second.
The selected beep volume level is set and the display returns to the previous
operating screen.
Tip You can also return to the previous screen by pressing 3 times.

Yaesu FTM-100DR/DE Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modulation Types	FM, C4FM
Display Type	Color TFT
Memory Channels	1000
GPS	Yes
APRS	Yes
Operating Modes	Simplex, Repeater
Supply Voltage	13.8V DC
Bluetooth	Yes
RF Power Output	50W
