Yaesu FTM-100DR/DE User Manual

153
Using the Optional Accessories (Bluetooth Devices/Voice Unit)
Using the Bluetooth headset
11 Reconnect the speaker cable extending from the top cover to the socket on the main
board.
12 Attach covers using the 8 screws.
Setting the Bluetooth headset operations
The following settings may be changed for convenient wireless headset operation
according to your personnel preferences.
• Listening to receive audio using the headset only, or listening with both the headset
and the transceiver speaker
• Saving the headset battery power
• Switching between transmit and receive with [PTT], or automatically switching to
transmit when you begin speaking [VOX]
• The [VOX] gain may be set to automatically switch to transmit upon detecting voices
including low volume sounds
1 Turn on the transceiver
2 Press and hold for over one second.
The Setup menu appears.
3 Rotate the DIAL to select [12 OPTION], then press
.
4 Rotate the DIAL to select [1 Bluetooth], then press
.
Tip This option can be selected only when BU-2 is installed
into the transceiver.
The settings screen appears.
5 Rotate the DIAL to select [1 AUDIO], then press
.
6 Rotate the DIAL to select “AUTO” or “FIX”.
“AUTO”: When a Bluetooth headset is connected, the audio from the radio speaker
is muted and sound is heard only from the headset.
“FIX”: Audio can be heard from both the Bluetooth headset and the speaker of the
transceiver.
Tip The default setting: AUTO

Yaesu FTM-100DR/DE Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modulation Types	FM, C4FM
Display Type	Color TFT
Memory Channels	1000
GPS	Yes
APRS	Yes
Operating Modes	Simplex, Repeater
Supply Voltage	13.8V DC
Bluetooth	Yes
RF Power Output	50W
