Basic Operations
Receiving
2 Rotate the DIAL to select [8 CONFIG], then press
.
The menu list appears.
3 Rotate the DIAL to select [7 FM AM STEP], then
press
.
4 Rotate the DIAL to select the desired frequency step.
The frequency steps change in the following order:
 “AUTO”→“5.00KHz”→“6.25KHz”→“8.33KHz”
→“10.00KHz”→“12.50KHz”→“15.00KHz”→
“20.00KHz”→“25.00KHz”→“50.00KHz”→
“100.00KHz”
Tips • The default setting: AUTO
 •The8.33kHzfrequencystepcanbeselectedonlyon
the Air band.
 •The5kHz,6.25kHzor15kHzfrequencystepcannot
beselectedon480MHzorhigherfrequency.
5 Press and hold for over one second.
The selected frequency step is set, and the display returns to the previous operating
display.
Tip To return to the previous operating display press 3 times.
Switching the operation mode
The operating mode can be switched between VFO mode and MEMORY mode. In VFO
mode, the operating frequency may be freely adjusted; in MEMORY mode, the memory
channels are recalled and displayed on the screen for operation.
1 Select the desired operating band.
2 Press .
The display switches to MEMORY mode.
or and the memory channel number appear
on the operating band name display.
Tips • appears on the A-band.
•
appears on the B-band.
When a name (tag) has been assigned to the
memory channel, the tag appears on the frequency
display or the sub-band display.

Yaesu FTM-100DR/DE Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modulation Types	FM, C4FM
Display Type	Color TFT
Memory Channels	1000
GPS	Yes
APRS	Yes
Operating Modes	Simplex, Repeater
Supply Voltage	13.8V DC
Bluetooth	Yes
RF Power Output	50W
