Yaesu FTM-100DR/DE User Manual

22
Installation and Connection
Installing the transceiver
Installation location when used in a mobile unit
● Front panel
To efficiently receive the GPS satellites, it is recommended that the transceiver should
be installed on the dashboard or front side of the center console. See “Installing the
front panel” on page 26
Tip The GPS reception antenna is built into the front panel.
Where the GPS antenna
is built in
● Main body
It is recommended that the main body be installed below the car dashboard or to either
side of the center console. See “Installing the main body” on page 25
Controller
Transceiver main body

Yaesu FTM-100DR/DE Specifications

General

Frequency Range	144-148 MHz, 430-450 MHz
Modulation Types	FM, C4FM
Display Type	Color TFT
Memory Channels	1000
GPS	Yes
APRS	Yes
Operating Modes	Simplex, Repeater
Supply Voltage	13.8V DC
Bluetooth	Yes
RF Power Output	50W
