Delaying Channel Signals 141
DM2000 Version 2—Owner’s Manual
Delaying Channel Signals
Input Channels, Bus Outs, Aux Sends, Matrix Sends, and the Stereo Out all feature inde-
pendent Delay functions. Input Channel Delays feature feedback, with independent Mix
and Gain parameters.
Using the SELECTED CHANNEL DELAY Controls
1 Use the LAYER buttons to select Layers, and use
the [SEL] buttons to select channels.
Use the STEREO [SEL] button to toggle between the left
and right channels of the Stereo Out. On the Master Layer, use [SEL] buttons 21–24 to tog-
gle between the left and right channels of the Matrix Sends.
2 Use the [ON] button to turn the Delay function on and off.
3 Use the TIME control to set the delay time.
If the currently selected channel is an Input Channel, you can also set the Feedback Gain
(FB) and Feedback Mix (MIX) parameters. Use the FB/MIX push switch to select either FB
or MIX, and use the FB/MIX control to set it.
Delay Pages
Delay settings can be viewed and set on the Delay pages. If the Auto DELAY Display prefer-
ence is on, these pages appear automatically when a control in the SELECTED CHANNEL
DELAY section is operated. See “Auto DELAY Display” on page 274.
1 Use the SELECTED CHANNEL DELAY [DISPLAY] button to select the Delay
pages.
The Delay parameters for the 96 Input Channels are arranged into four pages. The Input
Channel 1–24 Delay page is shown below. The layout of the other three pages is the same.
DELAY
ON
TIME
FB
MIX
DISPLAY

Yamaha DM2000 Specifications

General

Type	Digital Mixing Console
Channels	96
Sampling Rate	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Bit Depth	24-bit
Aux Sends	12
Matrix	8 x 8
EQ Bands	4-band parametric
Word Clock	Yes
Effects	Internal Effects Processors
Digital I/O	AES/EBU, ADAT
Display	LCD
