Yamaha DM2000 User Manual

Setting Send Levels 243
DM2000 Version 2—Owner’s Manual
Setting Send Levels
Send levels can be set as follows.
1 Use the AUX SELECT [AUX 1]–[AUX 5] (SEND A–E) buttons to select the
sends.
The ENCODER MODE [AUX/MTRX] (SEND LEVEL) button indicator lights up, as does
the button indicator of the selected send.
The levels for the selected send are displayed by the channel strip displays. See “Send Level”
on page 227 for more information.
2 Use the Encoders to set the send levels.
You can view send levels in dB on the channel strip displays by holding down the USER
DEFINED KEYS [13] (ALT/FINE) button while adjusting the Encoders.
Send levels can also be set by using the faders in Flip mode. See “Flip Mode” on page 243 for
more information.
Muting Sends
Sends can be muted as follows.
1 Press the MATRIX SELECT [MATRIX 2] (SEND MUTE) button.
2 Use the AUX SELECT [AUX 1]–[AUX 5] (SEND A–E) buttons to select the
sends.
The ENCODER MODE [AUX/MTRX] (SEND LEVEL) button indicator lights up, as does
the button indicator of the selected send.
3 Use the Encoder push-switches to mute the sends.
When a send is muted, the ring of the corresponding channel strip display flashes.
Sends can also be muted by using the [ON] buttons in Flip mode. See “Flip Mode” on page
243 for more information.
Panning Sends
Only sends assigned to stereo destinations can be panned. Sends can be panned by using the
Encoders in Flip mode. See “Flip Mode” on page 243 for more information.
Flip Mode
In Flip mode, the faders, Encoders, and [ON] buttons can be used to control sends, as
shown in the following table.
1 Press the FADER MODE [FADER] or [AUX/MTRX] button.
The FADER MODE [FADER] and [AUX/MTRX] button indicators flash alternately, and
both the ENCODER MODE [PAN] (PAN) and [AUX/MTRX] (SEND LEVEL) button
indicators light up. The SELECT ASSIGN section of the display shows “FLIP.”
2 Use the AUX SELECT [AUX 1]–[AUX 5] (SEND A–E) buttons to select the
sends.
The button indicator of the selected send lights up.
Control Normal mode Flip mode
Fader Channel level Send level
Encoder Channel pan/send level Send pan
[ON] button Channel mute Send mute

Yamaha DM2000 Specifications

General

Type	Digital Mixing Console
Channels	96
Sampling Rate	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Bit Depth	24-bit
Aux Sends	12
Matrix	8 x 8
EQ Bands	4-band parametric
Word Clock	Yes
Effects	Internal Effects Processors
Digital I/O	AES/EBU, ADAT
Display	LCD
