246 Chapter 19—Pro Tools Remote Layer
DM2000 Version 2—Owner’s Manual
Bypassing Individual Plug-ins
Individual plug-ins can be bypassed as follows.
(Make sure the EFFECTS/PLUG-INS [8] (INSERT/PARAM) button indicator is not lit
before proceeding.)
1 Press the ENCODER MODE [ASSIGN 4] (INSERT) button.
Its indicator lights up and the [SEL] buttons are set to Insert Select mode.
2 Use the [SEL] buttons to select plug-ins.
3 While holding down the EFFECTS/PLUG-INS [7] (BYPASS) button, use
Parameter control 1–4 push switches to bypass the plug-ins.
To bypass plug-in #5, press the Parameter Down (SCROLL >) button, and then perform
step 3. Press the Parameter Up (< SCROLL) button to view plug-ins 1–4 again.
The titles of bypassed plug-ins are displayed in uppercase characters. For example, the title
of the plug in “D-Verb” appears as “d-verb” when it’s not bypassed, and appears as
“D-VERB” when it is bypassed.
Bypassing all Plug-ins
All plug-ins on a channel can be bypassed as follows.
1 Press the MATRIX SELECT [MATRIX 4] (INSERT BYPASS) button.
Its indicator lights up.
The INS indicators on the channel strip displays work as follows.
INS indicator = off: None of the channel’s plug-ins are bypassed.
INS indicator = lit: All of the channel’s plug-ins are bypassed.
INS indicator = flashing: Some of the channel’s plug-ins are bypassed.
2 Press the ENCODER MODE [ASSIGN 4] (INSERT) button.
Its indicator flashes.
3 Use the [SEL] buttons to bypass all plug-ins on each channel.
The following shortcuts apply.
To do this... Do this!
Bypass all plug-ins on all channels
MATRIX SELECT [MATRIX 4], ENCODER MODE [ASSIGN 4],
USER DEFINED KEYS [5] + [SEL]
Bypass all plug-ins on all selected
channels
MATRIX SELECT [MATRIX 4], ENCODER MODE [ASSIGN 4],
USER DEFINED KEYS [5] + USER DEFINED KEYS [4] + [SEL]
