348 Appendix B: Specifications
DM2000—Owner’s Manual
Digital Input Spec
Digital Output Spec
Input Format Data length Level Connector
2TR IN DIGITAL
1
AES/EBU 24-bit RS422
XLR-3-31 type (Balanced)
1
1. XLR-3-31 type connectors are balanced (1=GND, 2=HOT, 3=COLD).
2
AES/EBU 24-bit RS422
XLR-3-31 type (Balanced)
1
3
IEC-60958 24-bit 0.5 Vpp/75 Ω RCA pin jack
CASCADE IN ——RS422
D-SUB Half Pitch Connector 68P
(Female)
Output Format Data length Level Connector
2TR OUT DIGITAL
1
AES/EBU
1
Professional use
1. Channel status of 2TR OUT DIGITAL 1, 2
Type: 2 audio channels
Emphasis: NO
Sampling rate: depends on the internal configuration
24-bit
2
2. Dither: word length 16/20/24 bit
RS422
XLR-3-32 type (Balanced)
3
3. XLR-3-32 type connectors are balanced (1=GND, 2=HOT, 3=COLD).
2
AES/EBU
1
Professional use
24-bit
2
RS422
XLR-3-32 type (Balanced)
3
3
IEC-60958
4
Consumer use
4. Channel status of 2TR OUT DIGITAL 3
Type: 2 audio channels
Category code: 2 channel PCM encoder/decoder
Copy prohibit: NO
Emphasis: NO
Clock accuracy: Level II (1000 ppm)
Sampling rate: depends on the internal configuration
24-bit
2
0.5V pp/75 Ω RCA pin jack
CASCADE OUT ——RS422
D-SUB Half Pitch Connector 68P
(Female)
