Selecting the Timecode Source & Frame Rate
The timecode source and frame rate for Automix can be set as follows.
1 Use the DISPLAY ACCESS [SETUP] button to select the Time Reference page.
2 Use the cursor buttons to select the parameters, and use the Parameter
wheel, INC/DEC buttons, and [ENTER] button to set them.
TIME REFERENCE:
The following timecode sources can be selected.
For the USB and SERIAL sources, you must specify a port from 1–8.
FRAMES: The frame rate can be set to: 30, 30D, 29.97, 29.97D, 25, or 24. An Automix will
playback correctly even if the frame rate is different to that which was used when the Auto-
mix was originally recorded.
The MIDI CLOCK source supports Song position Pointers, F8 TIMING CLOCK (timing
info), FA START (starts Automix from beginning), FB CONTINUE (starts Automix from
current position), and FC STOP (stops Automix).
Source Description
INTERNAL Internally generated timecode
SMPTE SMPTE timecode received via the SMPTE TIME CODE INPUT
MIDI CLOCK MIDI Clock received via the MIDI IN port
MTC MTC received via the MTC TIME CODE INPUT
USB MTC received via the USB TO HOST port
SERIAL MTC received via the SERIAL TO HOST port
SLOT1 MTC received via Slot #1 (for use with an optional mLAN I/O Card installed in Slot #1)
MIDI MTC received via the MIDI IN port

Yamaha DM2000 Specifications

General

Type	Digital Mixing Console
Channels	96
Sampling Rate	44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Bit Depth	24-bit
Aux Sends	12
Matrix	8 x 8
EQ Bands	4-band parametric
Word Clock	Yes
Effects	Internal Effects Processors
Digital I/O	AES/EBU, ADAT
Display	LCD
