294 Appendix A: Parameter Lists

DM2000 Version 2—Owner’s Manual

Output Patch Table 2

Direct Outs 2TR Digital Outs GEQs

Source Description Source Description Source Description

NONE NONE NONE NONE NONE NONE

S1-1 Slot1 CH1 OUT BUS1 BUS1 BUS1 BUS1

S1-2 Slot1 CH2 OUT BUS2 BUS2 BUS2 BUS2

S1-3 Slot1 CH3 OUT BUS3 BUS3 BUS3 BUS3

S1-4 Slot1 CH4 OUT BUS4 BUS4 BUS4 BUS4

S1-5 Slot1 CH5 OUT BUS5 BUS5 BUS5 BUS5

S1-6 Slot1 CH6 OUT BUS6 BUS6 BUS6 BUS6

S1-7 Slot1 CH7 OUT BUS7 BUS7 BUS7 BUS7

S1-8 Slot1 CH8 OUT BUS8 BUS8 BUS8 BUS8

S1-9 Slot1 CH9 OUT AUX1 AUX1 AUX1 AUX1

S1-10 Slot1 CH10 OUT AUX2 AUX2 AUX2 AUX2

S1-11 Slot1 CH11 OUT AUX3 AUX3 AUX3 AUX3

S1-12 Slot1 CH12 OUT AUX4 AUX4 AUX4 AUX4

S1-13 Slot1 CH13 OUT AUX5 AUX5 AUX5 AUX5

S1-14 Slot1 CH14 OUT AUX6 AUX6 AUX6 AUX6

S1-15 Slot1 CH15 OUT AUX7 AUX7 AUX7 AUX7

S1-16 Slot1 CH16 OUT AUX8 AUX8 AUX8 AUX8

S2-1 Slot2 CH1 OUT AUX9 AUX9 AUX9 AUX9

S2-2 Slot2 CH2 OUT AUX10 AUX10 AUX10 AUX10

S2-3 Slot2 CH3 OUT AUX11 AUX11 AUX11 AUX11

S2-4 Slot2 CH4 OUT AUX12 AUX12 AUX12 AUX12

S2-5 Slot2 CH5 OUT MATRIX1L MATRIX1 L MATRIX1L MATRIX1 L

S2-6 Slot2 CH6 OUT MATRIX1R MATRIX1 R MATRIX1R MATRIX1 R

S2-7 Slot2 CH7 OUT MATRIX2L MATRIX2 L MATRIX2L MATRIX2 L

S2-8 Slot2 CH8 OUT MATRIX2R MATRIX2 R MATRIX2R MATRIX2 R

S2-9 Slot2 CH9 OUT MATRIX3L MATRIX3 L MATRIX3L MATRIX3 L

S2-10 Slot2 CH10 OUT MATRIX3R MATRIX3 R MATRIX3R MATRIX3 R

S2-11 Slot2 CH11 OUT MATRIX4L MATRIX4 L MATRIX4L MATRIX4 L

S2-12 Slot2 CH12 OUT MATRIX4R MATRIX4 R MATRIX4R MATRIX4 R

S2-13 Slot2 CH13 OUT STEREO-L STEREO L STEREO-L STEREO L

S2-14 Slot2 CH14 OUT STEREO-R STEREO R STEREO-R STEREO R

S2-15 Slot2 CH15 OUT INSCH1 InsertOut-CH1 — —

S2-16 Slot2 CH16 OUT INSCH2 InsertOut-CH2 — —

S3-1 Slot3 CH1 OUT INSCH3 InsertOut-CH3 — —

S3-2 Slot3 CH2 OUT INSCH4 InsertOut-CH4 — —

S3-3 Slot3 CH3 OUT INSCH5 InsertOut-CH5 — —

S3-4 Slot3 CH4 OUT INSCH6 InsertOut-CH6 — —

S3-5 Slot3 CH5 OUT INSCH7 InsertOut-CH7 — —

S3-6 Slot3 CH6 OUT INSCH8 InsertOut-CH8 — —

S3-7 Slot3 CH7 OUT INSCH9 InsertOut-CH9 — —

S3-8 Slot3 CH8 OUT INSCH10 InsertOut-CH10 — —

S3-9 Slot3 CH9 OUT INSCH11 InsertOut-CH11 — —

S3-10 Slot3 CH10 OUT INSCH12 InsertOut-CH12 — —

S3-11 Slot3 CH11 OUT INSCH13 InsertOut-CH13 — —

S3-12 Slot3 CH12 OUT INSCH14 InsertOut-CH14 — —

S3-13 Slot3 CH13 OUT INSCH15 InsertOut-CH15 — —

S3-14 Slot3 CH14 OUT INSCH16 InsertOut-CH16 — —

S3-15 Slot3 CH15 OUT INSCH17 InsertOut-CH17 — —

S3-16 Slot3 CH16 OUT INSCH18 InsertOut-CH18 — —

S4-1 Slot4 CH1 OUT INSCH19 InsertOut-CH19 — —

S4-2 Slot4 CH2 OUT INSCH20 InsertOut-CH20 — —

S4-3 Slot4 CH3 OUT INSCH21 InsertOut-CH21 — —
