Yamaha F50F - Page 104

POWR
Power unit
5-13
6C13G11
5
No. Part name Q’ty Remarks
1 Throttle cam 1
2 Throttle control lever 1
3Bracket 1
4 Lever 1
5 Washer 1
6 Bushing 1
7 Clip 1
8Bolt 2 M6
×
25 mm
9Bolt 1 M6
×
35 mm
10 Collar 1
11 Wave washer 1
12 Cotter pin 1
Not reusable
13 Throttle cam roller 1
14 Bolt 1 M6
×
35 mm
15 Spring 1
16 Collar 1
S6C15070
AA
AA
AA
AA
4
8
3
5
6
7
16
15
2
14
13
12
1
11
10
9
8
