Yamaha F50F - Page 103

6C13G11
5-12
1
2
3
4
5
6
7
8
9
5
No. Part name Q’ty Remarks
18 Bolt 2 M6
×
20 mm
19 Holder 1
20 Bolt 1 M6
×
14 mm
21 Bolt 2 M8
×
25 mm
22 Bolt 1 M6
×
20 mm
23 Grommet 1
24 Holder 1
25 Bolt 1 M6
×
20 mm
26 Fuse 3 20 A
27 Cap 3
28 Bolt 2 M6
×
14 mm
29 Bolt 1 M6
×
14 mm
30 Screw 1 ø6
×
19 mm
31 Cap 2
32 Nut 2
33 Washer 2
34 Plastic tie 1
Not reusable
S6C15060
T
R
.
.
3 N
·
m (0.3 kgf
·
m, 2.2 ft
·
Ib)
T
R
.
.
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
T
R
.
.
3 N
·
m (0.3 kgf
·
m, 2.2 ft
·
Ib)
16
18
19
17
20
15
3
8
9
10
11
4
14
1
21
23
22
24
25
29
30
28
7
2
10
9
8
12
33
32
31
13
34
6
5
27
26
12
28
8
10
9
9
10
8
8
10
9
Power unit
