Yamaha F50F - Page 207

6C13G11
7-10
1
2
3
4
5
6
7
8
9
7
No. Part name Q’ty Remarks
18 Bolt 1 M6
×
25 mm
19 Fuel joint 1
20 Seal 1
21 Bottom cowling assembly 1
22 Bolt 1 M6
×
20 mm
23 Holder 1
24 Washer 1
25 Washer 1
26 Holder 1
27 Nut 1
28 Fuel hose 1
29 Joint 1
30 Fuel hose 1
31 Corrugated tube 1
32 Holder 1
33 Bracket 1
34 Bolt 1 M6
×
15 mm
S6C17060
T
R
.
.
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
AA
AA
1
2
3
4
5
7
AA
6
8
9
10
11
12
13
14
16
15
17
18
19
20
21
22
24
25
23
27
33
32
34
31
30
29
28
26
T
R
.
.
18 N
·
m (1.8 kgf
·
m, 13.3 ft
·
Ib)
LT
242
Bottom cowling
