Yamaha F50F - Page 268

ELEC
Electrical systems
– +
8-17
6C13G11
8
No. Part name Q’ty Remarks
18 Brush assembly 1
19 Brush spring 4
20 Brush holder 1
21 Plate 1
22 Washer 1
23 Bracket 1
24 Screw 2 ø4
×
15 mm
25 Bolt 2 M6
×
120 mm
26 Rubber seal 1
27 Shift lever 1
28 Spring 1
29 Magnet switch assembly 1
30 Washer 1
31 Nut 1
S63P8050
24
25
23
21
20
18
17
16
15
7
8
9
10
11
26
12
13
14
27
29
31
28
6
5
4
3
2
1
22
19
19
19
19
30
