Yamaha F50F - Page 97

6C13G11
5-6
1
2
3
4
5
6
7
8
9
5
No. Part name Q’ty Remarks
1 Power unit 1
2 Oil dipstick 1
3Gasket 1
Not reusable
4 Dowel 2
5Bolt 2 M6
×
16 mm
6Bolt 8 M8
×
80 mm
7 Apron 1
8Screw 2 ø6
×
24 mm
9Nut 2
10 Flywheel magnet cover 1
11 Grommet 2
12 Neutral switch 1 Tiller handle model
13 Shift position switch 1
14 Bolt 2 M6
×
20 mm
15 Screw 2 ø4
×
16 mm
16 Plate 1
17 Collar 1
Power unit
