Yamaha F50F - Page 98

POWR
Power unit
5-7
6C13G11
5
No. Part name Q’ty Remarks
1Nut 1
2 Washer 1
3 Flywheel magnet 1
4Bolt 3 M6
×
30 mm
5 Stator coil 1
6 Stator coil bracket 1
7Bolt 4 M6
×
30 mm
8 Collar 2
9 Pulser coil 1
10 Bolt 2 M5
×
12 mm
11 Woodruff key 1
12 Bolt 1 M6
×
20 mm
