Yamaha WR250F 2021 - FRONT BRAKE

FRONT BRAKE
4-16
EAM20097
FRONT BRAKE
Removing the front brake caliper
Order Job/Parts to remove Q’ty Remarks
Brake fluid
Drain.
Refer to “BLEEDING THE HYDRAULIC
BRAKE SYSTEM” on page 3-25.
1 Union bolt 1
2 Copper washer 2
3 Front brake hose 1
4 Brake pad pin plug 1
5 Brake pad pin 1
6 Brake pad 2
7 Brake pad spring 1
8 Front brake caliper assembly 1
9 Front brake caliper bracket 1
3
9
1
2
8
4
5
7
6
28 N・m (2.8 kgf・m, 21 lb・ft)
30 N・m (3.0 kgf・m, 22 lb・ft)
6 N・m (0.6 kgf・m, 4.4 lb・ft)
2.5 N・m (0.25 kgf・m, 1.8 lb・ft)
17 N・m (1.7 kgf・m, 13 lb・ft)
