Yamaha WR250F 2021 - Camshaft

CAMSHAFT
5-14
EAM20106
CAMSHAFT
* Yamaha bond No. 1215 (Three bond No.1215®)
Removing the cylinder head cover
Order Job/Parts to remove Q’ty Remarks
Seat
Refer to “GENERAL CHASSIS” on page
4-1.
Side cover (left/right)
Refer to “GENERAL CHASSIS” on page
4-1.
Air scoop (left/right)
Refer to “GENERAL CHASSIS” on page
4-1.
Fuel tank Refer to “FUEL TANK” on page 7-1.
Ignition coil Refer to “ENGINE REMOVAL” on page 5-6.
1 Cylinder head breather hose 1
2 Spark plug 1
3 Cylinder head cover 1
4 Timing chain guide (top side) 1
5 Cylinder head cover gasket 1
1
2
3
4
5
10 N・m (1.0 kgf・m, 7.4 lb・ft)
13 N・m (1.3 kgf・m, 9.6 lb・ft)
