CHARGING SYSTEM
8-13
EAM30283
TROUBLESHOOTING
The battery is not being charged.
Before troubleshooting, remove the following part(s):
1. Seat
2. Air scoop (left)
1. Check the entire charging system’s
wiring.
NG
Reconnect.
OK
2. Check the fuse.
Refer to “CHECKING THE FUSES”
on page 8-59.
NG
Replace the fuse(s).
OK
3. Check the battery.
Refer to “CHECKING AND
CHARGING THE BATTERY” on
page 8-60.
NG
• Clean the battery terminals.
• Recharge or replace the battery.
OK
4. Check the rectifier/regulator.
Refer to “CHECKING THE RECTI-
FIER/REGULATOR” on page 8-67.
NG
Replace the rectifier/regulator.
OK
5. Check the stator coil assembly.
Refer to “CHECKING THE STA-
TOR COIL” on page 8-67.
NG
Replace the stator coil assembly.
OK
6. Check the charging system wire
harness.
Refer to “CIRCUIT DIAGRAM” on
page 8-11.
NG
Repair or replace the wire harness.
OK
This circuit is OK.
To Next Page
