DESCRIPTION
1-5
EAM20086
DESCRIPTION
Designs and specifications of the vehicle are subject to change without notice. Therefore, please note
that the descriptions in this manual may be different from those for the vehicle you have purchased.
1
1413
1517 16
18
19202122
5
68 7910
1211
42, 3
1. Clutch lever
2. Engine trouble warning light “ ”
3. Fuel level warning light “ ”
4. Multi-function display
5. Front brake lever
6. Throttle grip
7. Start switch
8. Radiator cap
9. Fuel tank cap
10.Engine stop switch
11.Taillight
12.Fuel tank
13.Headlight
14.Radiator
15.Coolant drain bolt
16.Oil level check window
17.Rear brake pedal
18.Air filter
19.Drive chain
20.Shift pedal
21.Starter knob
22.Front fork
