VALVES AND VALVE SPRINGS
5-26
EAM20108
VALVES AND VALVE SPRINGS
Removing the valves and valve springs
Order Job/Parts to remove Q’ty Remarks
Cylinder head Refer to “CYLINDER HEAD” on page 5-21.
1 Valve lifter 4
2 Adjusting pad 4
3 Valve cotter 8
4 Valve spring retainer 4
5 Valve spring 4
6 Valve stem seal 4
7 Valve spring seat 4
8 Intake valve 2
9 Exhaust valve 2
E
1
1
2
2
3
3
3
3
4
4
5
5
6
6
7
7
8
9
