CRANKCASE
5-67
Removing the bearing and oil seal
Order Job/Parts to remove Q’ty Remarks
Transmission Refer to “TRANSMISSION” on page 5-73.
Shift cam/Shift fork Refer to “TRANSMISSION” on page 5-73.
1 Circlip 2
2 Oil seal 3
3 Bearing 13
1
2
3
3
3
3
3
3
3
E
E
E
E
LT
3
3
3
3
LT
E
LT
E
3
E
1
2
2
LT
LT
12 N・m (1.2 kgf・m, 8.9 lb・ft)
22 N・m (2.2 kgf・m, 16 lb・ft)
12 N・m (1.2 kgf・m, 8.9 lb・ft)
