THROTTLE BODY
7-5
Removing the throttle body
Order Job/Parts to remove Q’ty Remarks
11 Throttle cable 2
12 Fuel hose 1
13 Throttle body 1
14 Exhaust pipe bracket 1
15 Throttle body joint 1
(2)
(2)
(2)
11
11
11
11
13
15
14
12
7 N・m (0.7 kgf・m, 5.2 lb・ft)
7 N・m (0.7 kgf・m, 5.2 lb・ft)
10 N・m (1.0 kgf・m, 7.4 lb・ft)
8 N・m (0.8 kgf・m, 5.9 lb・ft)
3.5 N・m (0.35 kgf・m, 2.6 lb・ft)
3.0 N・m (0.30 kgf・m, 2.2 lb・ft)
4.3 N・m (0.43 kgf・m, 3.2 lb・ft)
3.0 N・m (0.30 kgf・m, 2.2 lb・ft)
3.8 N・m (0.38 kgf・m, 2.8 lb・ft)
