YASKAWA E-II Series User Manual

6 Wiring
6.3.3 I/O Signal (CN1) Names and Functions
6-12
6.3.3 I/O Signal (CN1) Names and Functions
(1) Input Signals
Note: 1. Pin numbers in parentheses () indicate signal grounds.
2. The functions allocated to /S-ON, /P-CON. P-OT, N-OT, /ALM-RST, /P-CL, and /N-CL input
signals can be changed by using the parameters. Refer to 7.3.2 Input Circuit Signal Allocation.
3. The voltage input range for speed and torque references is a maximum of ±12 V.
Signal Name Pin No. Function
Refer-
ence
Common
/S
-
ON
40
Servo ON: Turns ON the servomotor when the gate block in the inverter is released.
8.3.1
/P
-
CON
41
Function selected by parameter.
−
Proportional control
reference
Switches the speed control loop from PI (proportional/
integral) to P (proportional) control when ON.
8.5.2
9.4.4
Direction reference
With the internally set speed selection: Switch the rotation
direction.
8.8.2
Control mode
switching
8.10.2
Zero-clamp reference
Speed control with zero-clamp function: Reference
speed is zero when ON.
8.5.6
Reference pulse block
Position control with reference pulse stop: Stops reference
pulse input when ON.
8.6.7
P
-
OT
N
-
OT
42
43
Forward run
prohibited
Reverse run
prohibited
Overtravel prohibited: Stops servomotor when movable part
travels beyond the allowable range of motion.
8.3.3
/P
-
CL
/N
-
CL
45
46
Function selected by parameter.
−
Forward external
torque limit ON
Reverse external
torque limit ON
External torque limit function enabled when ON.
8.9.2
Internal speed
switching
With the internally set speed selection: Switches the
internal speed settings.
8.8.2
8.10.2
/ALM
-
RST
44
Alarm reset: Releases the servo alarm state.
8.11.1
+24VIN
47
Control power supply input for sequence signals: Users
must provide the +24 V
po
wer supply.
Allowable voltage fluctuation range: 11 to 25 V
6.3.4
SEN
4 (2)
Initial data request signal when using an absolute encoder.
8.4.1
BAT (+)
BAT (-)
21
22
Connecting pin for the absolute encoder backup battery.
Do not connect when a battery is connected to the host controller.
6.2.1
8.4.3
Speed
V
-
REF
5 (6)
Speed reference speed input: ±2 to ±10 V/rated motor speed (Input gain can be
modified using a parameter.)
8.5.2
Torq u e
T
-
REF
9 (10)
Torque reference input: ±1 to ±10 V/rated motor torque (Input gain can be modified
using a parameter.)
8.7.2
Position
PULS
/PULS
SIGN
/SIGN
7
8
11
12
Reference pulse input
for line driver and open
collector
Input mode is set from the following pulses.
• Sign + pulse string
• CCW/CW pulse
• Two-phase pulse (90° phase differential)
8.6.1
CLR
/CLR
15
14
Positional error pulse clear input: Clears the positional error pulse during position
control.
8.6.1
PL1
PL2
PL3
3
13
18
+12 V pull-up power is supplied when PULS, SIGN, and CLR reference signals are
open-collector outputs (+12 V power supply is built into the SERVOPACK).
6.3.4
8.6.3
Position speed
Position
torque
Torque speed
Enables control mode switching.
↔
↔
↔
