4.6 SERVOPACK Dimensional Drawings
4
SERVOPACK Specifications and Dimensional Drawings
4-21
4.6.7 Three-phase 400 V, 90 kW Model
(1) SGDH-9ZDEB
24 450 24
498
20 1060
1100
611
395
4×M12 mounting holes
Units: mm
Approx.mass: 130 kg
