3.2 Ratings and Specifications of SGMVH (800 min
-1
)
3
Servomotor Specifications and Dimensional Drawings
3-7
(b) 400 V Class
* These items and torque-motor speed characteristics quoted in combination with SGDM/SGDH
SERVOPACK are at an armature winding temperature of 20°C.
Note: These characteristics are values with the following iron plates (heat sinks) attached for
cooling.
SGMVH-2B: 650 × 650 × 35 mm
SGMVH-3Z, 3G and 4E: 740 × 520 × 27 mm
Voltage Class 400 V
Servomotor Model
SGMVH-
2BDD3ZDD3GDD4EDD
Rated Output
∗
kW
22 30 37 45
Rated Torque
∗
N·m
262 358 442 537
Stall Torque
∗
N·m
262 358 442 537
Instantaneous Peak Torque
∗
N·m
526 752 930 1182
Rated Current
∗
Arms
52 75 98 110
Instantaneous Max. Current
∗
Arms
120 170 230 280
Rated Speed
∗
min
-1
800
Max. Speed
∗
min
-1
1300
Torque Constant N·m/Arms
5.46 5.00 4.68 5.21
Rotor Moment of Inertia J
x10
-4
kg·m
2
705 1290 1564 1804
Rated Power Rate
∗
kW/s
979 994 1248 1600
Rated Angular Acceleration
∗
rad/s
2
3726 2777 2824 2978
