2.5 Selecting Peripheral Devices
2
Selections
2-7
* For details, refer to the manuals of each application module.
Name Length Type Specifications
Refer-
ence
c
I/O Signal
Cables
Connector terminal block
converter unit
JUSP-TA50PG
Terminal block and 0.5 m connection
cable
5.5.4
Cable with
loose wires at
one end
1 m JZSP-CKI01-1
Loose wires at host controller end
5.4.1
2 m JZSP-CKI01-2
3 m JZSP-CKI01-3
d Digital Operator
JUSP-OP02A-2
With connection cable (1 m)
5.5.2
e
Connection Cable for Digital
Operator
1m JZSP-CMS00-1
Required only when the digital oper-
ator model: JUSP-OP02A-1 for Σ-I
series is used.
1.5m JZSP-CMS00-2
2 m JZSP-CMS00-3
f
Connection Cable for Personal
Computer
2 m JZSP-CMS01
D-Sub 25-pin (For PC98)
5.5.1
2 m JZSP-CMS02
D-Sub 9-pin (For DOS/V)
2 m JZSP-CMS03
Half-pitch 14-pin (For PC 98)
g
Analog Monitor Cable
1 m
JZSP-CA01 or
DE9404559
5.5.3
h
Battery for Absolute Encoder
JZSP-BA01-1
5.5.6
ER6VC3
To connect to a host controller,
3.6 V, 2000 mAh
,
manufactured by
Toshiba Battery Co., Ltd.
⑦
Application Module
∗
JUSP-NS100
MECHATROLINK-I application
module (NS100)
5.5.15
JUSP-NS115
MECHATROLINK-II application
module (NS115)
5.5.15
JUSP-NS300
DeviceNet application module
(NS300)
5.5.16
JUSP-FC100
Fully-closed application module
(FC100)
5.5.18
JUSP-NS500
PROFIBUS-DP
application module (NS500)
5.5.17
CN1
CN3
Operator
end
SERVOPACK
end
CN3
Personal
computer end
SERVOPACK
end
Personal
computer end
SERVOPACK
end
Personal
computer end
SERVOPACK
end
CN5
SERVOPACK end
Monitor end
CN8
