5.4 I/O Signal Cables for CN1 Connector
5
Specifications and Dimensional Drawings of Cables and Peripheral Devices
5-11
(2) Dimensional Drawing of Connector
(3) Cable Size
2.54
Units: mm
1.27
Pin No. 26
Pin No. 1
15q
2.3
㧟㧹
5.1
36.7
30.48
1.27
41.1
(6.6)
19.3
(2.9)
12.7
9.1
7.5
Item Specifications
Cable Use twisted-pair or twisted-pair shielded wire.
Applicable Wires AWG24, 26, 28, 30
Finished Dimension φ16 mm or less
