YASKAWA E7 Drive User Manual

Physical Installation 1 - 2
 E7 Model Number and Enclosure Style
The E7 Drive covers two voltage ranges: 208-240Vac and 480Vac. Applicable ratings vary from 0.5 to 500 HP.
Table 1.1 E7 Model Numbers and Enclosure Style
3-Phase
Voltage
E7
Model-Number
Enclosure Style
208-240Vac
CIMR-E7U20P4 NEMA 1 (IP20)
CIMR-E7U20P7 NEMA 1 (IP20)
CIMR-E7U21P5 NEMA 1 (IP20)
CIMR-E7U22P21 NEMA 1 (IP20)
CIMR-E7U23P7 NEMA 1 (IP20)
CIMR-E7U25P5 NEMA 1 (IP20)
CIMR-E7U27P5 NEMA 1 (IP20)
CIMR-E7U2011 NEMA 1 (IP20)
CIMR-E7U2015 NEMA 1 (IP20)
CIMR-E7U2018 NEMA 1 (IP20)
CIMR-E7U2022 NEMA 1 (IP20)
CIMR-E7U2030 NEMA 1 (IP20)
CIMR-E7U2037 Open Chassis (IP00)
CIMR-E7U2045 Open Chassis (IP00)
CIMR-E7U2075 Open Chassis (IP00)
CIMR-E7U2090 Open Chassis (IP00)
CIMR-E7U2110 Open Chassis (IP00)
480 Vac
CIMR-E7U40P4 NEMA 1 (IP20)
CIMR-E7U40P7 NEMA 1 (IP20)
CIMR-E7U41P5 NEMA 1 (IP20)
CIMR-E7U42P2 NEMA 1 (IP20)
CIMR-E7U43P7 NEMA 1 (IP20)
CIMR-E7U45P5 NEMA 1 (IP20)
CIMR-E7U47P5 NEMA 1 (IP20)
CIMR-E7U4011 NEMA 1 (IP20)
CIMR-E7U4015 NEMA 1 (IP20)
CIMR-E7U4018 NEMA 1 (IP20)
CIMR-E7U4030 NEMA 1 (IP20)
CIMR-E7U4037 NEMA 1 (IP20)
CIMR-E7U4045 NEMA 1 (IP20)
CIMR-E7U4055 NEMA 1 (IP20)
CIMR-E7U4075 Open Chassis (IP00)
CIMR-E7U4090 Open Chassis (IP00)
CIMR-E7U4110 Open Chassis (IP00)
CIMR-E7U4160 Open Chassis (IP00)
CIMR-E7U4185 Open Chassis (IP00)
CIMR-E7U4220 Open Chassis (IP00)
CIMR-E7U4300 Open Chassis (IP00)
