Digital Operator 3 - 12
Quick Setting Menu
This menu is used to set/read the most commonly used parameters in the Drive. Follow the key operations below to access the
Quick Setting Menu:
Fig 3.6 U1 Monitor List Access Procedure
Use and keys to scroll through the “Quick Setting” parameter list.
Table 3.11 Quick Setting Parameter List
Parameter
Number
Parameter Name Parameter
Number
Parameter Name
A1-00 Language Selection b5-29 PI Square Root Gain
b1-01 Frequency Reference Selection b5-30 Output Square Root Monitor Selection
b1-02 Run command Selection b8-01 Energy Savings Control Selection
b1-03 Stopping Method Selection C1-01 Acceleration Time 1
b1-04 Reverse Operation Selection C1-02 Deceleration Time 1
b5-01 PI Mode Selection d2-01 Frequency Reference Upper Limit
b5-02 Proportional Gain Setting d2-02 Frequency Reference Lower Limit
b5-03 Intregral Time Setting E1-01 Input Voltage Setting
b5-04 Intregral Limit Setting E2-01 Motor Rated Current
b5-06 PI Output Limit F6-01 Operation Selection After Communication Error
b5-07 PI Offset Adjustment H3-02 Terminal A1 Gain Setting
b5-08 PI Primary Delay Time H3-03 Terminal A1 Bias Setting
b5-09 PI Output Level Selection H3-10 Terminal A2 Gain Setting
b5-10 PI Output Gain Setting H3-11 Terminal A2 Bias Setting
b5-11 PI Output Reverse Selection L2-01 Momentary Power Loss Detection Selection
b5-12 PI Feedback Reference Missing Detection Selection L2-02 Momentary Power Loss Ride-thru Time
b5-13 PI Feedback Loss Detection Level L4-05 Frequency Reference Loss Detection Selection
b5-14 PI Feedback Loss Detection Time L4-06 Frequency Reference Level at Loss Frequency
b5-15 PI Sleep Function Start Level L5-01 Number of Auto Restarts Attempts
b5-16 PI Sleep Delay Time L5-03 Maximum Restart Time After Fault
b5-17 PI Accel/Decel Time L6-01 Torque Detection Selection 1
b5-18 PI Setpoint Selection L6-02 Torque Detection Level 1
b5-19 PI Setpoint Value L6-03 Torque Detection Time 1
b5-20 PI Setpoint Display Setting L8-11 Heatsink Cooling Fan Operation Delay Time
b5-21 PI Sleep Input Source o1-01 User Monitor Selection
b5-22 PI Snooze Level o1-05 LCD Brightness Adjustment
b5-23 PI Snooze Delay Time o1-07 Second Line User Monitor Selection
b5-24 PI Snooze Deactivation Level o1-08 Third Line User Monitor Selection
b5-25 PI Setpoint Boost Setting o2-03 User Parameter Default Value
b5-26 PI Maximum Boost Time o2-05 Frequency Operation Time Selection
b5-27 PI Snooze Feedback Level o2-08 Cumulative Operation Time Selection
b5-28 PI Feedback Square Root Ac Function Selection o3-02 Read Allowed Selection
-QUICK-
** Main Menu **
- - - - - - - - - - - - - -
Quick Setting
-QUICK-
Reference Source
- - - - - - - - - - - - - - - - - - - -
B1-01= 1 *1*
Terminals
“1”
x2
To Next Page
