Electrical Installation 2 - 2
Terminal Block Configuration
The wiring terminals are shown in Fig 2.1, Fig 2.2 and Fig 2.3.
Fig 2.1 Terminal Configuration for Models CIMR-E7U2018/4018 and smaller
Fig 2.2 Terminal Configuration for Models CIMR-E7U2022/4030 and larger
Fig 2.3 Control Circuit Terminal Layout
Charge indicator
Ground terminal
Control circuit terminals
Main circuit terminals
Control circuit terminals
Ground terminal
(See Figure 2.3)
Ground terminal
Charge indicator
Control circuit terminals
(See Figure 2.3)
Ground terminal
Main circuit terminals
