YASKAWA E7 Drive User Manual

Digital Operator 3 - 7
Drive Main Menus
The Drive’s parameters and monitoring functions are organized into groups called menus that make it easier to read and set
parameters. The Drive is equipped with five menus. The five menus and their primary functions are shown in Table 3.7.
Table 3.7 Drive Main Menus
Main Menu Primary Function(s)
Operation
- DRIVE -
The Drive can be run in this menu.
Use this menu for monitoring values such as frequency reference or output current, displaying fault his-
tory or displaying the fault traces.
Quick Setting
- QUICK -
The Drive can be programmed in this menu.
Use this menu to set/read the most commonly used parameters.
Programming
- ADV -
The Drive can be programmed in this menu.
Use this menu to set/read every parameter.
Modified Constants
- VERIFY -
The Drive can be programmed in this menu.
Use this menu to set/read the parameters that have been modified from their factory default settings.
Auto-Tuning
- A.TUNE -
The Drive can be programmed in this menu.
Use this menu to auto-tune the Drive in order to optimize motor control as well as utilize the bi-directional
speed search feature.
