Physical Installation 1 - 11
Checking and Controlling Installation Site
Install the Drive as described below and maintain optimum conditions.
Installation Site
Install the Drive under the following conditions in Pollution Degree 1 & 2 environments per UL Standards. This excludes wet
locations where surfaces may become conductive due to moisture and contaminant loading.
Protective covers are attached to the top and bottom of the Drive. It is recommended to remove the protective covers before
operating a CIMR-E7U2030/4055 Drive and smaller in a panel to obtain the 113° (45°C) ambient operating temperature.
Observe the following precautions when installing the Drive:
• in a clean location which is free from oil mist and dust.
• in an environment where metal shavings, oil, water, or other foreign materials do not get into the Drive.
• in a location free from radioactive materials and combustible materials (e.g. wood).
• in a location free from harmful gasses and liquids.
• in a location free from excessive vibration.
• in a location free from chlorides.
• in a location away from direct sunlight.
Controlling the Ambient Temperature
To enhance the reliability of operation, the Drive should be installed in an environment free from extreme temperature
variations. If the Drive is installed in an enclosure, use a cooling fan or air conditioner to maintain the internal air temperature
below 113°
F (45°C).
Protecting the Drive from Foreign Matter
During Drive installation, it is possible to have foreign matter, such as metal shavings or wire clippings, fall inside the Drive.
To prevent foreign matter from falling into the Drive, place a temporary cover over the Drive.
Always remove the temporary cover from the Drive after completing installation. Otherwise, ventilation will be reduced, caus-
ing the Drive to overheat.
Table 1.3 Installation Site Specifications
Type Ambient Operating Temperature Humidity Plenum Rated
NEMA 1 Type 14° F -to- 104°F ( - 1 0 -to- + 40 °C) 95%-RH-or-less-(no-condensation) Yes
Open Chassis 14° F -to- 113°F ( - 1 0 - to -+ 4 5 °C ) 9 5 % -RH-or-less-(no-condensation) No
To Next Page
