Digital Operator 3 - 2
Digital Operator
The Digital Operator is used for programming, operating, and monitoring drive operation. The E7 Drive will not run unless the
digital operator is securely attached to the Drive.
Digital Operator Display
The various items included on the Digital Operator are described below.
Fig 3.1 Digital Operator Component Names and Functions
Drive Mode Indicators
See Table 3.2
Data Display
Displays monitor data, parameter numbers and settings
Key Descriptions
See Table 3.1
RUN & STOP Indicators
See Tables 3.5 and 3.6
Ready Display
Drive can operate when a drive command is input
-DRIVE- Rdy
Frequency Ref
U1-01= 60.00Hz
- - - - - - - - - - - - - - - - - - - - - - - - - - - - -
U1-02= 60.00Hz
U1-03= 10.05A
1 line x 13 characters
3 lines x 16 characters
Menu Display
See Table 3.7
To Next Page
