YASKAWA E7 Drive User Manual

Spare Parts F - 3
 E7 Primary Spare Parts - 480Vac
Table F.3 480Vac E7 Primary Spare Parts
Drive Model
CIMR-E7U
Power PCB
(3PCB)
Gate Drive PCB
(3PCB)
Control PCB
(1PCB)
Ter minal PC B
(2PCB)
Diode Module
40P4 ETP617082 N/A ETC618021-S3010 ETC618141 Inside the Power Module
40P7 ETP617082 N/A ETC618021-S3010 ETC618141 Inside the Power Module
41P5 ETP617092 N/A ETC618021-S3010 ETC618141 Inside the Power Module
42P2 ETP617102 N/A ETC618021-S3010 ETC618141 Inside the Power Module
43P7 ETP617112 N/A ETC618021-S3010 ETC618141 Inside the Power Module
45P5 ETP617132 N/A ETC618021-S3010 ETC618141 Inside the Power Module
4011 ETP617152 N/A ETC618021-S3010 ETC618141 Inside the Power Module
4015 ETP617162 N/A ETC618021-S3010 ETC618141 SID003112 (D1)
4018 ETP617172 N/A ETC618021-S3010 ETC618141 SID000605 (D1)
4030 N/A ETC617151 ETC618021-S3010 ETC618141 SID003112 (D1,D2)
4037 N/A ETC617161 ETC618021-S3010 ETC618141 SID003112 (D1,D2)
4045 N/A ETC617171 ETC618021-S3010 ETC618141 SID000605 (D1,D2)
4055 N/A ETC617181 ETC618021-S3010 ETC618141 SID000605 (D1,D2)
4075 N/A ETC617190 ETC618021-S3010 ETC618141 SID003117 (D1,D2)
4090 N/A ETC617200 ETC618021-S3010 ETC618141 SID003117 (D1,D2)
4110 N/A ETC617210 ETC618021-S3010 ETC618141 SID003109 (D1,D6)
4160 N/A ETC617230 ETC618021-S3010 ETC618141 SID003119 (D1,D6)
4185 N/A ETC617240 ETC618021-S3010 ETC618141 SID003119 (D1,D6)
4220 N/A ETC617250 ETC618021-S3010 ETC618141 SID003131 (D1,D6)
4300 N/A ETC617260 ETC618021-S3010 ETC618141 SID003119(D1,D12)
Table F.4 480Vac E7 Primary Spare Parts
Drive Model
CIMR-E7U
Power Module Transistor Module DC Bus Fuse Heat Sink Fan Internal Fan
40P4 STR001298 (Q1) N/A FU-002029 (F1) N/A N/A
40P7 STR001298 (Q1) N/A FU-002029 (F1) N/A N/A
41P5 STR001298 (Q1) N/A FU-002029 (F1) N/A N/A
42P2 STR001298 (Q1) N/A FU-002029 (F1) N/A N/A
43P7 STR001300 (Q1) N/A FU-002031 (F1) FAN001041 (B1) N/A
45P5 STR001302 (Q1) N/A FU-002031 (F1) FAN001041 (B1) N/A
4011 N/A STR001280 (Q1) FU-002037 (F1) FAN001041 (B1,B2) FAN001043 (B3)
4015 N/A STR001318 (Q1) FU-002038 (F1) FAN001042 (B1,B2) N/A
4018 N/A STR001318 (Q1) FU-002038 (F1) FAN001042 (B1,B2) FAN001043 (B3)
4030 N/A STR001324 (Q1) FU-002039 (F1) FAN001039 (B1,B2) N/A
4037 N/A STR001316 (Q1-Q3) FU-002040 (F1) FAN001044 (B1,B2) N/A
4045 N/A STR001317 (Q1-Q3) FU-002040 (F1) FAN001044 (B1,B2) N/A
4055 N/A STR001317 (Q1-Q3) FU-002101 (F1) FAN001044 (B1,B2) N/A
4075 N/A STR001294 (Q1-Q3) FU-002112 (F1) FAN001052 (B1,B2) FAN001054 (B4)
4090 N/A STR001336 (Q1-Q6) FU-002113 (F1) FAN001052 (B1,B2) FAN001054 (B4)
4110 N/A STR001336 (Q1-Q6) FU-002114 (F1) FAN001056 (B1,B2) FAN001054 (B4)
4160 N/A STR001322 (Q1-Q3) FU-000895 (F1) FAN001056 (B1,B2) FAN001054 (B4)
4185 N/A STR001339 (Q1-Q12) FU-000895 (F1) FAN001056 (B1,B4) FAN001054 (B6,B7)
4220 N/A STR001341 (Q1-Q12) FU-002116 (F1) FAN001056 (B1,B4) FAN001054 (B6,B7)
4300 N/A STR001342 (Q1-Q12) FU-002117 (F1) FAN001082 (B1,B5) FAN001054 (B6,B7)
