YASKAWA E7 Drive User Manual

Capacity Related Parameters B - 2
If a Control PCB is changed, the next time the Drive is powered up, parameter o2-04 must be set to the appropriate value listed
in Table B.1 for the Drive model number. This will automatically program the values of all other parameters listed in Table B.2
to the factory settings for that particular Drive rating.
Parameter o2-04 sets the Drive capacity according to the model number. Parameter o2-04 will need to be adjusted when
replacing a control board.
Table B.1 Drive Capacity Selection
Voltage E7 Model Number o2-04 Setting
208-240Vac
CIMR-E7U20P4 0
CIMR-E7U20P7 1
CIMR-E7U21P5 2
CIMR-E7U22P2 3
CIMR-E7U23P7 4
CIMR-E7U25P5 5
CIMR-E7U27P5 6
CIMR-E7U2011 7
CIMR-E7U2015 8
CIMR-E7U2018 9
CIMR-E7U2022 A
CIMR-E7U2030 B
CIMR-E7U2037 C
CIMR-E7U2045 D
CIMR-E7U2055 E
CIMR-E7U2075 F
CIMR-E7U2090 10
CIMR-E7U2110 11
480Vac
CIMR-E7U40P4 20
CIMR-E7U40P7 21
CIMR-E7U41P5 22
CIMR-E7U42P2 23
CIMR-E7U43P7 24
CIMR-E7U45P5 26
CIMR-E7U47P5 27
CIMR-E7U4011 28
CIMR-E7U4015 29
CIMR-E7U4018 2A
CIMR-E7U4030 2C
CIMR-E7U4037 2D
CIMR-E7U4045 2E
CIMR-E7U4055 2F
CIMR-E7U4075 30
CIMR-E7U4090 31
CIMR-E7U4110 32
CIMR-E7U4160 34
CIMR-E7U4185 35
CIMR-E7U4220 36
CIMR-E7U4300 37
.
