YASKAWA E7 Drive User Manual

Quick Reference for E7 Parameters
Parameter
Number
Factory
Setting
User
Setting
Parameter
Number
Factory
Setting
User
Setting
Parameter
Number
Factory
Setting
User
Setting
Parameter
Number
Factory
Setting
User
Setting
A1-00 0 b5-06 100 E1-06 60 L3-06 120
A1-01 2 b5-07 0 E1-07 3 L4-01 0
A1-03 0 b5-08 0 E1-08 18 L4-02 2
A1-04 0 b5-09 0 E1-09 1.5 L4-05 1
A1-05 0 b5-10 1 E1-10 10.8 L4-06 80
A2-01 b5-11 0 E1-11 0 L5-01 0
A2-02 b5-12 0 E1-12 0 L5-02 0
A2-03 b5-13 0 E1-13 0 L5-03 10
A2-04 b5-14 1 E2-01 kVA Dep. L6-01 6
A2-05 b5-15 0 E2-03 kVA Dep. L6-02 15
A2-06 b5-16 0 E2-05 kVA Dep. L6-03 10
A2-07 b5-17 0 F6-01 1 L8-01 0
A2-08 b5-18 0 F6-02 0 L8-02 95
A2-09 b5-19 0 F6-03 1 L8-03 4
A2-10 b5-20 1 F6-05 0 L8-06 5
A2-11 b5-21 1 H1-01 24 L8-09 1
A2-12 b5-22 0 H1-02 14 L8-10 0
A2-13 b5-23 0 H1-03 3 L8-11 300
A2-14 b5-24 0 H1-04 4 L8-12 45
A2-15 b5-25 0 H1-05 6 L8-15 1
A2-16 b5-26 0 H2-01 0 L8-18 1
A2-17 b5-27 60 H2-02 A L8-19 20
A2-18 b5-28 0 H3-02 100 n1-01 1
A2-19 b5-29 1 H3-03 0 n1-02 1
A2-20 b5-30 0 H3-08 2 n3-01 5
A2-21 b8-01 0 H3-09 2 n3-02 150
A2-22 b8-04 kVA Dep. H3-10 100 n3-03 1
A2-23 b8-05 20 H3-11 0 n3-04 40
A2-24 b8-06 0 H3-12 0.3 o1-01 6
A2-25 C1-01 30 H3-13 0 o1-02 1
A2-26 C1-02 30 H4-01 2 o1-03 0
A2-27 C1-03 30 H4-02 100 o1-05 3
A2-28 C1-04 30 H4-03 0 o1-06 0
A2-29 C1-09 10 H4-04 8 o1-07 2
A2-30 C1-11 0 H4-05 50 o1-08 3
A2-31 C2-01 0.2 H4-06 0 o2-01 1
A2-32 C2-02 0.2 H4-07 0 o2-02 1
b1-01 1 C4-01 1 H4-08 0 o2-03 0
b1-02 1 C4-02 200 H5-01 1F o2-04 kVA Dep.
b1-03 0 C6-02 kVA Dep. H5-02 3 o2-05 1
b1-04 1 C6-03 kVA Dep. H5-03 0 o2-06 1
b1-07 0 C6-04 kVA Dep. H5-04 3 o2-07 0
b1-08 0 C6-05 0 H5-05 1 o2-08 1
b1-11 0 d1-01 0 H5-06 5 o2-09 1
b1-12 0 d1-02 0 H5-07 1 o2-10 0
b2-01 0.5 d1-03 0 H5-08 0 o2-12 0
b2-02 50 d1-04 0 H5-09 2 o2-14 0
b2-03 0 d1-17 6 L1-01 1 o2-15 1
b2-04 0 d2-01 100 L1-02 8 o3-01 0
b2-09 0 d2-02 0 L1-03 3 o3-02 0
b3-01 2 d2-03 0 L1-04 1 T1-02 kVA Dep.
b3-02 120 d3-01 0 L1-05 0.2 T1-04 kVA Dep.
b3-03 2 d3-02 0 L2-01 2
b3-05 0.2 d3-03 0 L2-02 0.1
b3-14 1 d3-04 1 L2-03 0.1
b4-01 0 d4-01 0 L2-04 0.3
b4-02 0 d4-02 10 L2-05 190
b5-01 0 E1-01 240V or 480V L3-01 1
b5-02 2 E1-03 F L3-02 120
b5-03 5 E1-04 60 L3-04 1
b5-04 100 E1-05 240V or 480V L3-05 1
