YASKAWA E7 Drive User Manual

Start Up 4 - 6
 9. Press the 扶 key once to display E2-01 “Motor Rated FLA”.
This parameter is the foundation of motor protection. It can be set automatically when auto-tuning is performed. Set
this parameter according to the motor rated current (FLA). Press the DATA/ENTER once. Use the 扶 , ▼ , and 斧
keys to adjust E2-01 to the motor rated full load amps.
Ensure the DATA/ENTER key is pressed to enter the value in the Drive. “Entry Accepted” briefly appears and your
display is not flashing.
 10. Press the ESC once. Press DATA/ENTER once. Press 扶 key twice to display b1-02 “Run Source”. This parameter
selects where the Drive will receive the run command. Press the DATA/ENTER key once. Use the
扶 or ▼ keys and
the DATA/ENTER key to set this parameter per the application.
Ensure the DATA/ENTER key is pressed to enter the selection in the Drive. “Entry Accepted” briefly appears and
the display is now not flashing.
 11. Press the
▼ key once to display b1-01 “Reference Source”. This parameter selects where the Drive will receive the
speed command. Press the DATA/ENTER key once. Use the 扶 or ▼ keys and the DATA/ENTER key to set this
parameter per the application.
Ensure the DATA/ENTER key is pressed to enter the selection in the Drive. “Entry Accepted” briefly appears and
the display is now not flashing.
Table 4.6 Motor Rated Current
Parameter
No.
Parameter Name
Digital Operator Display
Setting
Range
Factory
Setting
Menu
Location
E2-01
Motor Rated Current
Motor Rated FLA
kVA
Dependent
kVA
Dependent
Quick Setting
Table 4.7 Run Command Selection
Parameter
No.
Parameter Name
Digital Operator Display
Setting Choices
Setting
Range
Factory
Setting
Menu Location
b1-02
Run Command Selection
Run Source
0: Operator
1: Terminals
2: Serial Com
3: Option PCB
0 - 3 1 Quick Setting
Table 4.8 Speed Command Selection
Parameter
No.
Parameter Name
Digital Operator Display
Setting
Choices
Setting
Range
Factory
Setting
Menu Location
b1-01
Frequency Reference
Selection
Reference Source
0: Operator
1: Terminals
2: Serial Com
3: Option PCB
0 - 3 1 Quick Setting
